Leica Elmarit-M 28mm f2.8 ASPH.

One of the cheapest, which is certainly not noticeable in it's performance.

17 Photos

france_paris_versailles_louvre_landscape_pyramid_28mm_elmarit

Leica M (Typ 240) | Elmarit-M 28mm ASPH.

The Leica Elmarit-M 28mm ASPH. at a glance

The Leica Elmarit-M 1:2,8/28mm ASPH. is a wide angle lens for M mount cameras and serves as a 36mm lens on the M8 and M8.2. Back then when I used the M8 and M8.2 it was my most used lens. It might not be very fast at only f/2,8 but it is razor sharp and has virtually no distortion what so ever. It is more sharp and has less distortion than the more expensive Leica Summicron-M 1:2/28mm ASPH. but is one aperture stop slower. It only weighs approximately 180 grams, is very small so doesn’t block your viewfinder at all and has the E39 filter size which is nice if you have other lenses in that size. It is also one of the cheapest Leica lenses with only the Summarit line being cheaper.

You can click images to enlarge them.

greece_corfu_28mm_elmarit_asph_man
greece_corfu_28mm_elmarit_asph_on_edge_cliff

Leica M9-P | Elmarit-M 28mm ASPH.

Great starter lens combined with a Leica M8 or M8.2

If you don’t have a Leica yet but would like to get your first Leica, you will probably be shocked and amazed by how expensive the lenses and camera bodies are. Most people start by buying a second hand body. And with the introduction of the M (Typ 240) the prices of the M8, M8.2, M9 and M9-P have dropped significantly. If you want to start out as cheap as possible it’s better to save money on the body than on the lenses, because the lenses only go up in price over time and you will bring the lenses to your next M body when you upgrade later on. This Leica Elmarit-M 28mm ASPH. combined with a M8 or M8.2 is a great starter set with a approximate 36mm equivalent focal length due to the M8 and M8.2’s x1,33 crop factor.

belgium_liege_luik_train_station_28mm_elmarit_asph

Leica M8.2 | Elmarit-M 28mm ASPH.

The lens on the full frame bodies

The lens performs just as well on the fullframe bodies as it does on the x1,33 crop M8 and M8.2 and only has a very tiny amount of distortion in the very far corners and a little vignetting. But it has the real 75˚ diagonal viewing angle. It is great for street photography, get in close and intimate with your subject. Or for architecture and landscapes. This lens is a great performer for allot of different subjects. And for the price it goes for should be in any M owner’s camera bag.

france_paris_appartment_leica_28mm_elmarit_asph_lorenz_r

Leica M (Typ 240) | Elmarit-M 28mm ASPH.

Performance

The lens has only very little vignetting on full frame bodies wide open, and only very little distortion in the very far corners. It is very sharp from f/2,8 – f/8 with it’s sweet spot I would say at f/4. From f/11 and smaller you will notice diffraction limiting the sharpness slightly but the lens is still sharp enough and if you need it for a very large depth of field you can easily stop down to the smallest aperture setting on this lens: f/22. The lens does flare when there is a direct light source just outside of the frame, but the supplied lens hood will keep this from happening when attached. It has a 10 bladed aperture diaphragm making for nice ‘sunstars’ when shooting night time cityscapes for example.

On the x1,33 crop bodies this lens is perfect. It is sharp and has no vignette not even wide open. The lens on full frame bodies is already that good, and if you ‘crop’ the image slightly like the M8 and M8.2 do you end up with a photo that is near perfect.

germany_duisburg_boys_climbing_typ240_28mm_elmarit_asph_3
belgium_antwerp_industria_flash_28mm_high_iso_elmarit_asph_2
belgium_antwerp_industria_flash_28mm_high_iso_elmarit_asph_cropped_vertical_2

Leica M (Typ 240) | Elmarit-M 28mm ASPH.

Handling

The lens handles great, it is a really light weight at only 180 grams, so you barely feel it is there on the camera. It has a nice focus tab just like the 35mm Summicron-M ASPH. or the 50mm Summilux-M ASPH. etc. It has a short focus throw but is precise enough to get accurate focus quickly and consistently. The aperture ring is very smooth with half stop clicks, in my opinion it’s a bit too smooth just like most other modern Leica lenses. Sometimes I accidentally change the aperture value when I am wearing gloves, for example. All in all handling is pretty much the same as the 35mm Summicron-M ASPH. the lenses also look alike but the 35mm Summicron-M ASPH. is a lot heavier and slightly taller. It also doesn’t protrude into the viewfinder so you get a clear view on your subject.

france_southern_france_monochrom_28mm_elmarit_asph_2

Leica M (Typ 240) | Elmarit-M 28mm ASPH.

A few more images for you to enjoy

Below you will find a few more shots taken with the Elmarit-M 28mm ASPH. I hope you’ve enjoyed reading and checking out the images in my article – as always feel free to subscribe to my newsletter to receive a email when I write a new article, or to leave your thoughts in the comments bellow.

Donations are really welcome too since a lot of time goes into writing these articles. Donations can be made through Paypal to paypal@jipvankuijk.nl or contact me if you wish to donate in another way.

Thanks.

greece_corfu_leica_elmarit_28mm_asph_kerkyra
belgium_ardennes_28mm_asph_elmarit
france_louvre_lens_28mm_elmarit_asph
belgium_molsbroek_nature_sunset_28mm_elmarit_lorenz
